JL Industries 8435 Crownline Recessed Fire Department Valve Cabinet, Flat Trim Trim, Stainless Steel

The JL Industries 8435 is a Crownline series fully recessed fire department valve cabinet in stainless steel with flat trim trim. Crownline is the large-format architectural cabinet for fire department valves, hose racks and extinguishers, covering the 6000-7200 and 8000 series. Trim and door are cold rolled steel, 304 stainless steel or aluminum, finished in white powder coat, #4 stainless or clear anodized aluminum. The tub is white powder coated cold rolled steel, with surface mount models in the same material as the door and trim. Sizes range from an 18" x 18" x 8" single valve cabinet up to 32-3/4" x 38-3/4" x 8" for a 125 foot hose rack plus a valve or extinguisher, and a 16" x 40" x 9" dual valve-plus-extinguisher cabinet.

Configure this cabinet

Door style: Full Glass, Full Glass + Saf-T-Lok, Vertical Duo, Vertical Duo + Saf-T-Lok, Horizontal Duo, Horizontal Duo + Saf-T-Lok, Solid Door, Solid Door + Saf-T-Lok. Saf-T-Lok (SL-LC) is the standard lock for most locking cabinets: a theft-deterrent keyed cylinder lock used instead of a break glass lock lever, since breaking glass in a panic can injure people and create liability. The door appears locked and is, but a sharp pull breaks or bends a replaceable plastic cam and opens it. The cam is 1-5/8" x 1" x 3/32" and is replaced with a Phillips head screwdriver.

Glazing: Glazing 10 is 0.090" clear acrylic, the standard clear glazing. Glazing 13 is 1/4" clear wire with safety film, shown in the catalog as WireShield. Glazing 15 is 1/8" bronze acrylic, for a tinted door. Glazing 16 is 1/8" gray acrylic, a neutral tint. Glazing 17 is 1/8" clear tempered glass. Glazing 18 is 1/4" clear safety glass, shown in the catalog as laminated safety.

Pull / handle: Pull handles are 4" CTC in finishes matching the cabinet material, with a standard zinc pull (PUS) on most cabinets. The flush recessed pull (PRH, model suffix A) is a plastic cup-type handle, standard on all 4" trim cabinets and optional elsewhere; on a vertical duo door it moves the window to the right. The chrome lever handle (LH) is optional on cabinets without Saf-T-Lok.

Colored powder-coat finishes, magnetic catches, decorative bronze or brass pulls, Futura cast handles, wired glass and alarms are available on request — ask for a quote with your model number.

Dimensions

• Trim: Flat Trim
• Approx. ship weight: 22 lb

ADA Standards for protruding objects specify that objects projecting from walls with leading edges between 27" and 80" above the finished floor shall protrude no more than 4" into walkways. The ADA also states the cabinet handle cannot be mounted higher than 48" AFF where only a forward approach in a wheelchair is possible. Trimless, 3/8" flat, 2-1/4" and 1-1/2" square, 3" rolled and 4" rolled trims meet the 4" rule; 4-1/2" rolled and surface mount do not.

Availability: built to order by JL Industries to the configuration you select. Ask us for the current lead time before you schedule an install.

Model number key: tub 84 = 18" x 18" x 10"; material Stainless Steel; trim Fully Recessed 3/8" Flat Trim, Square Edge. All fire protection products carry a one year warranty after the date of shipment against defects in materials and workmanship, and the manufacturer will replace or repair any product found defective within this period at its discretion. No other warranty expressed or implied is valid; fire extinguishers may carry a longer warranty and manufacturer's warranty terms and conditions apply in all cases.
