JL Industries 1053 Cavalier Surface-Mounted Fire Extinguisher Cabinet, Brass

The JL Industries 1053 is a Cavalier series surface-mounted fire extinguisher cabinet in brass, built around a 10-1/2" x 24" x 6" tub. The Cavalier is the decorative bronze and brass cabinet, specified where lobbies, hotels and similar interiors call for a metal finish that matches door hardware rather than a painted or stainless cabinet. Trim and door are bronze or brass in US10 satin bronze, US10B oil-rubbed bronze or US3 polished brass; door pulls match the finish of the cabinet. The tub is cold rolled steel with white powder coat, and surface mount models match the trim material. US9 bright polished bronze and US4 satin brass are available as additional options. Cavalier is offered in the 18, 10 and 20 tub sizes with flat, square, rolled and surface mount trims.

Fits: Cosmic 2.5 lb - 10 lb, Galaxy 2.5 lb - 10 lb, Mercury 2.5 lb - 5 lb, Sentinel 5 lb.

Configure this cabinet

Door style: Full Glass, Full Glass + Saf-T-Lok, Vertical Duo, Vertical Duo + Saf-T-Lok, Horizontal Duo, Horizontal Duo + Saf-T-Lok, Solid Door, Solid Door + Saf-T-Lok. Saf-T-Lok (SL-LC) is the standard lock for most locking cabinets: a theft-deterrent keyed cylinder lock used instead of a break glass lock lever, since breaking glass in a panic can injure people and create liability. The door appears locked and is, but a sharp pull breaks or bends a replaceable plastic cam and opens it. The cam is 1-5/8" x 1" x 3/32" and is replaced with a Phillips head screwdriver.

Glazing: Glazing 10 is 0.090" clear acrylic, the standard clear glazing. Glazing 15 is 1/8" bronze acrylic, for a tinted door. Glazing 16 is 1/8" gray acrylic, a neutral tint. Glazing 17 is 1/8" clear tempered glass. Glazing 18 is 1/4" clear safety glass, shown in the catalog as laminated safety.

Pull / handle: Pull handles are 4" CTC in finishes matching the cabinet material, with a standard zinc pull (PUS) on most cabinets. The flush recessed pull (PRH, model suffix A) is a plastic cup-type handle, standard on all 4" trim cabinets and optional elsewhere; on a vertical duo door it moves the window to the right. The chrome lever handle (LH) is optional on cabinets without Saf-T-Lok.

Colored powder-coat finishes, magnetic catches, decorative bronze or brass pulls, Futura cast handles, wired glass and alarms are available on request — ask for a quote with your model number.

Dimensions

• Tub (inside): 10-1/2" x 24" x 6" (W x H x D)
• Overall size: 13-11/16" W x 27-3/16" H x 6-1/2" D
• Trim / frame outside: 13-7/8" x 27-3/8"
• Approx. ship weight: 17 lb

Availability: built to order by JL Industries to the configuration you select. Ask us for the current lead time before you schedule an install.

Model number key: tub 10 = 10-1/2" x 24" x 6"; material Brass; trim Surface Mount, Square Edge. All fire protection products carry a one year warranty after the date of shipment against defects in materials and workmanship, and the manufacturer will replace or repair any product found defective within this period at its discretion. No other warranty expressed or implied is valid; fire extinguishers may carry a longer warranty and manufacturer's warranty terms and conditions apply in all cases.
