- Model
- MB811C
- Ship weight
- 4.0 lb
JL Industries Mark MB811C Fire Extinguisher Mounting Bracket
FSP · P-02
What it is
JL Industries Mark MB811C is a steel wall or vehicle mounting bracket for JL Industries C model portable fire extinguishers, finished in black powder paint, meets astm b-117 and tested to UL 240. It fits Cosmic 20E (FE20C and FE20CBV), Galaxy 20 (FG20C), Sentinel 20 (FS20C) and Purple K 20 and 30 (FPK20C, FPK20CBV, FPK30CBV). JL supplies a J-hook as standard with these extinguishers, so this bracket is the optional strap and latch upgrade. UL requires a hanging device to withstand five times the weight of the charged extinguisher and not less than 100 pounds. Wall fasteners are not included.
The JL Industries Mark MB811C is a steel wall or vehicle mounting bracket for JL's C model portable fire extinguishers. JL supplies a J-hook as standard with most extinguishers; the Mark brackets are the strap and latch style option used where the extinguisher has to be held positively, such as on a vehicle, in a corridor subject to knocks, or inside a cabinet tub. It fits Cosmic 20E (FE20C and FE20CBV), Galaxy 20 (FG20C), Sentinel 20 (FS20C) and Purple K 20 and 30 (FPK20C, FPK20CBV, FPK30CBV).
- Material: Steel
- Finish: Black powder paint, meets ASTM B-117
- Test standard: UL 240
- Fits: Cosmic 20E (FE20C and FE20CBV), Galaxy 20 (FG20C), Sentinel 20 (FS20C) and Purple K 20 and 30 (FPK20C, FPK20CBV, FPK30CBV)
- Other reference numbers: 700229/811
- In the box: one Mark MB811C bracket. Wall fasteners are not included; JL's owner's manual specifies the fastener type for wood stud, sheetrock, cinderblock, concrete, tile and steel substrates.
- Selection note: JL's bracket submittal says to select C brackets for C model extinguishers and A brackets for A model extinguishers.
- Load: UL specifies that a hanging device must withstand a vertical force of five times the weight of the charged extinguisher, and not less than 100 pounds.
Extinguishers this bracket is listed for on this store: FE20C, FG20C, FS20C.
The owner's manual notes that for marine use, a US Coast Guard approval is valid only when the extinguisher is fitted with the approved marine-type bracket named on its nameplate.
JL Industries warrants fire protection products other than extinguishers, including brackets, free from defects in materials and workmanship for one year from date of shipment; manufacturer warranty terms and conditions apply in all cases.
FSP · P-03
Submittal data
The same values print on the submittal sheet.
| Construction | |
|---|---|
| Material | Steel |
| Finish | Black powder paint, meets ASTM B-117 |
| Dimensions and weight | |
|---|---|
| Bracket size | Not published in the manufacturer's submittal text |
| Mounting and standards | |
|---|---|
| Test standard | UL 240 |
| Hanging device load | Five times the weight of the charged extinguisher, not less than 100 lb (UL) |
| Fits extinguisher models | Cosmic 20E (FE20C and FE20CBV), Galaxy 20 (FG20C), Sentinel 20 (FS20C) and Purple K 20 and 30 (FPK20C, FPK20CBV, FPK30CBV) |
| Bracket family | C model extinguishers |
| Warranty | One year from date of shipment |
| Item | |
|---|---|
| JL Industries item number | MB811C |
| Other reference numbers | 700229/811 |
| JL stock list | Not listed |
FSP · P-04
Documents
FSP · P-05
General notes
Which extinguishers does the Mark MB811C fit?
Cosmic 20E (FE20C and FE20CBV), Galaxy 20 (FG20C), Sentinel 20 (FS20C) and Purple K 20 and 30 (FPK20C, FPK20CBV, FPK30CBV).
What is the Mark MB811C made of?
Steel, finished in black powder paint, meets astm b-117.
Is the Mark MB811C UL listed?
JL's submittal gives UL 240 as the test standard for this bracket.
Do I need this bracket if I already bought the extinguisher?
Not necessarily. JL supplies a J-hook wall bracket as standard with these extinguishers; the Mark bracket is the optional strap and latch alternative.
Are wall fasteners included?
No. JL's owner's manual specifies the screw or anchor type for wood stud, sheetrock, cinderblock, concrete, tile and steel substrates.
